Goyen RCA5D

Goyen RCA5D

1. Description
This product has been designed with a 4.76mm (3/16″) orifice and under the full range
of voltages, can operate all of Goyen’s current main valve assemblies used in reverse
pulse cleaning systems.
Unit weight : 0.338 Kg (0.744 lbs).

2. Flow Performance
The pilot valve orifice: 5 mm (3/16″)
Flow Performance: .68 Cv/.58 kV

3. Pressure Rating
Maximum Working Pressure: 860 kPa (125 psi)
Recommended Working Pressure: 760 kPa (110 psi)
Minimum Working Pressure: 30 kPa (5 psi)

4. Temperature Rating
Working Temperature Range: -40°C to 80°C (-40°F to 176°F)
Fluid Media
Dry air or inert gas

5. Power Consumption & Duty Cycle Power consumption per operating coil:
– 110/120 VAC 19 W
– 220 V 50 Hz 11 W
– 24 V DC 24 W

6. Duty Cycle
Maximum coil “on time” 500 milliseconds

7. Connection Types
Pilot Inlet and Outlet connections: 1/4″ BSP T(RC) & 1/4″ NPT

8. Mounting Details
Individual pilot mounting hole size ∅19.3mm (∅.760″), minimum wall thickness 1.5mm
(.062″)
